1505-8 KA DT BW
£200.00
In stock
SKU
560120
PLEASE NOTE:
We strongly recommend that you spare parts fitted by a qualified guitar technician, electrical service engineer or your local music store.
- Guitar Nuts and Saddles are a default size that may require cutting, sanding or shaping to suit your guitar's unique requirements.
- Bridge pins are also made to a standard size that may require a little sanding to ensure a correct fit as Faith Guitars are handmade and the holes hand-drilled and reamed.
- Removal and replacement of guitar bridges should only be attempted by a professional.
- Guitar pickups and preamps are delicate and will require some technical skill to remove and re-fit.
- Electrical compoments for amplifiers, mixers etc should only ever be fitted by a qualified professional.
We accept no liability for any damage caused by incorrectly fitted spare parts.
Handling & Shipping Charges
| Delivery Destination | Cost (£) |
|---|---|
| United Kingdom (Royal Mail Parcel) | £7.50 |
| Ireland | £10.00 |
| Channel Islands | £18.00 |
(All prices include UK VAT @ 20%)
| Barcode | 0014367124675 |
|---|---|
| Product It Fits: | 115 Int. Series III Black, DTH Sub, HDH1, HDH2, SP 115M, SP1G, SP2G, SP2Ti, SP3G, SP7G, UDH Sub Woofer |
| Peavey Part Number | 560120 |
| Product Type: | Speakers |
| BL (T/M) | 17.7 |
| Cms (uM/N) | 145.3 |
| Disp (cu. In. / ml) | 197 / 3229 |
| Frequency Range | 40 Hz - 2 Hz |
| Le (mH) | 0.28 |
| Mms (gm) | 68.5 |
| Net Weight | 17 lbs / 7.7 kg |
| No (%) | 4.5 |
| Pmax (Watts pgm) | 700 |
| Power - Continuous | 350W |
| Power - Peak | 1400W |
| Power - Program | 700W |
| Qes | 0.367 |
| Qms | 7.6 |
| Qts | 0.35 |
| Replacement Basket | 560130 |
| Revc (ohms) | 5.23 |
| Sensitivity | 99.0 dB / 1W 1m |
| SPL (1W 1m) | 99 |
| Vas (Litres) | 143.5 |
| Vd (cu. in. /ml) | 4.6 / 76 |
| Voice Coil Diameter | 4.0" / 100mm |
| Voice Coil Material | Aluminium ribbon wire; Polyimide-impregnated fibreglass former Nomex stiffened; OFHC copper leads |
| Xmax (mm) | 0.9 |
| Znom (ohms) | 8 |
